CoaxPress Grabber Board

Next-Level Performance fof High-Speed Vision Systems

Multi-lane CXP12 bandwidth enables seamless transmission of
ultra-high-speed image data. Real-time image processing ensures
both high inspection accuracy and speed. Reliable signal transmission
allows flexible integration into a wide  range of vision systems.

  • HVG-CXP12-X4 (G3x8): CoaXPress 1.1, 2.0, 2.1
  • Four (4X) CoaXPress CXP 12 connections (Micro BNC)
  • PCIe 3.0 (Gen 3) x 8 bus
  • Camera Types: Area/Line Scan, Monochrome/Color
  • Feature rich set of 20 digital I/O lines
  • JIIA international standard certification

  • Fan-cooled heatsink

  • Extensive camera control functions

  • Feature-rich set of 20 digital I/O lines

Main Features

1
Ultra High Speed Image Acquisition & Data Transfer
With up to 2× the bandwidth of previous generations
and data transfer speeds of up to 12.5 Gbit/s × 8 lanes,
it enables exceptional performance for high speed
imaging applications.
3
Compact Size
Compact 132 × 103 mm form factor, smaller than comparable
competing products enables flexible system configuration
even in space constrained installation environments.
2
Debug Log Viewer Software
Monitor inspection equipment in real time with dedicated
debugging software. Featuring Eye Scan, Signal & Performance
Graphs, and Internal Log Monitoring, it enables rapid system
diagnostics while supporting seamless integration with vision software.
4
A Supply Partner with Competitive
Edge in Delivery, Quality, Price
Stable supply and rapid delivery response deliver
approx 40% cost savings compared to competing solutions.
5
Key Domestic and International Certifications
Certified under JIIA, KC, FCC, CE, and other major standards,
our products meet the requirements of both domestic and
international markets, including Europe and the United States.
Ready to support global customers across a wide range
of projects with fast, flexible deployment.

Certifications

A verified Product that has completed JIIA international standard certification, as well as FCC, CE, KC, and RoHS certifications.

Specifications

Item
CoaXPress Grabber Board (HVG-CXP12-x4(G3x8))
PC Interface
PCI Express Gen3, 8Lane
Camera Interface
CoaXPress 2.1
CXP HOST Connector
4 x Micro-BNC ( impedence 75Ω )
Camera connection

 One 1- or 2- connection camera

 Two 1- or 2- connection camera

 Four connection camera

  - 1Lane camera :  x 1 connection , x2 connections, x3 connections, x4 connections

  - 2Lane camera : x 1 connection , x2 connections

  - 4Lane camera : x 1 connection

Power

PoCXP Power : 17W of 24V DC regulated per CoaXPress connector

On-board 12V to 24V DC/DC converter

GPIO

D-sub Connector (26Pin)

-  High-speed differential Input : 2

-  Isolated Input : 4

-  Isolated Output : 2

-  TTL Input / Output : 2

Board Size
132 x 103mm
With PCI-E PCB Slot
132 x 114mm
